Philips DreamStation Auto CPAP With Humidifier, INTL

Intended Use: The Philips Respironics DreamStation system deliver positive airway pressure therapy for the treatment of Obstructive Sleep Apnea in spontaneously breathing patients weighing over 30 kg (66Ibs). It is for use in the home or hospital/institutional environment.

Important: The device is to be used on the instruction of a licensed physician. Your home care provider will make the correct pressure setting and device configurations including accessories, according to your health care professional’s prescription.

Several accessories are available to make your OSA treatment with the DreamStation system as convenient and comfortable as possible. To ensure that you receive the safe, effective therapy prescribed for you, use only Philips Respironics accessories.

This figure illustrates some of the device features, described in the following table.

1. Therapy On/Off Button: Start and stops the airflow for therapy. If the Therapy On/Off button LED is flashing, you may have a pending message. Press or turn the knob to display the message.
2. Ambient Light Sensor: Detect room light levels and adjusts the brightness of the Display Screen.
3. Ramp Button: Activates the ramp features during therapy.
4. Door, SD card & Filter Access: This door lifts open for access to the SD card and filter area.
5. Display Screen: This is the User Interface for the therapy device.
6. Control Dial: Turn the dial to scroll between options on the screen. Press the dial to choose an option.
7. Door, Accessory Access: This door lifts open for access to the (optional) accessories.
8. Humidifier Connector: Humidifier connects to the back of the therapy device. The humidifier pin connector will attach here.
9. Air Outlet Port: Connect the tubing here.
10. Power Inlet: Connect the power cord here.

Philips Respironics DreamStation Heated Humidifier

Intended Use: The DreamStation Heated Humidifier is an accessory for the Philips Respironics Dreamstation therapy devices to provide moisture to the patient circuit. It is intended for use in spontaneously breathing patients weighing over 30 kg (66Ibs), in the home or hospital/ instruction environment, who use mask-applied positive ventilation therapy.

This figure illustrates some of the device features, described in the following table.

1. Humidifier: Connect your therapy device here.
2. Air Inlet Port: Connects to the outlet port on the therapy device
3. Air Outlet Port: Connect the tubing here.
4. Humidifier Lid Release Latch: Slide this latch to open the humidifier lid.
5. Water Tank: This one-piece removable water tank holds the water for humidification.
6. Maximum Fill Lines: These fill lines indicate the maximum water level for safe operation.
7. Humidifier Lid: Open the lid and access the water tank.
8. Humidifier Lid Seal: Seals the water tank to the humidifier lid.
9. Flexible Heated Tubing (optional): The optional heated tube connects from the humidifier to your mask.
10. Humidifier Connector End: Connect this end of the tubing to the humidifier.
11. Heated Plate: Warms the water in the water tank.
12. Humidifier Release Button: Press this button to remove the humidifier from the therapy device. Refer to the “Disconnecting the Therapy Device” section of this manual to see this button.
13. Therapy Device: The heated humidifier connects to the back of the therapy device.

Limited Warranty (3 Months) Against Manufacturing Defects.
